Operating Table TY-1
Reviews (0)Brightfield Healthcare TY-1 is an operating table with a 2000 × 500 mm top rated for patients up to 200 kg. The top is lifted hydraulically from 750 to 1000 mm, while the sections and tilts are set mechanically with handles and foot pedals – a robust choice for general, gynaecological, ENT, urological and orthopaedic surgery.
Product Speciality
About product
Simple Mechanics, Dependable Positioning
On the TY-1 only the lift of the top is hydraulic. Every other position is set by hand using handles and foot pedals, so none of the table’s movements depends on an electric drive or a control unit.
Room for Larger Patients and Taller Teams
The 2000 mm top and a maximum load of 200 kg suit heavier and taller patients. The upper height limit of 1000 mm lets the surgical team work at a comfortable level during long standing procedures.
Tilts and Sections
- Trendelenburg / reverse Trendelenburg – 25° in both directions.
- Side tilt – 20° to the left and to the right.
- Headrest – 45° up, 70° down.
- Back section – 75° up, 15° down.
- Leg section – 15° / 90° / 90°.
- Kidney bridge – 110 mm.
What Comes in the Box
The table is delivered with an anaesthesia screen, a pair of lateral body supports, a pair of arm rests, a pair of shoulder supports, a pair of leg holders, six fixing clamps and a mattress. A set of traumatology and orthopaedic attachments is available on request.
Fields of Use
- General and abdominal surgery
- Gynaecology and obstetrics
- Ophthalmology and otorhinolaryngology
- Urology and orthopaedics
The metal frame and fittings are stainless steel, resistant to chemical disinfectants. For theatres that prefer a slightly lighter table with pedal-controlled hydraulic height, the TS-1 (170 kg, 1970 mm top) is the alternative.
