Light Source – POWER LED 180
Reviews (0)
The Brightfield POWER LED 180 is an endoscopic LED light source delivering light output comparable to a 180 W Xenon system. With a daylight-balanced colour temperature of 5,500 K and a CRI of 95, it provides high-quality illumination and natural colour reproduction during endoscopic procedures.
Its LED technology offers an operational life of more than 50,000 hours, eliminating the need for costly Xenon lamp replacements. The unit has a power consumption of 70 VA and is designed for integration into endoscopic imaging systems.
Description
Daylight-Balanced LED Illumination for Endoscopy
The Brightfield POWER LED 180 is an LED light source designed for endoscopic visualization. It delivers light output comparable to a 180 W Xenon source while using LED technology that eliminates the need for regular Xenon lamp replacement.
With a colour temperature of 5,500 K and a colour rendering index of 95, the POWER LED 180 provides daylight-balanced illumination with accurate colour reproduction. These characteristics are particularly important during endoscopic procedures, where the surgical team relies on a clear view of tissue structures and their natural appearance.
Natural Colour Reproduction with CRI 95
Colour accuracy plays an important role in endoscopic imaging. The POWER LED 180 has a Colour Rendering Index (CRI) of 95, allowing tissue colours to appear closer to their natural appearance under the light source.
Its 5,500 K colour temperature produces daylight-like illumination, providing a suitable light source for use with endoscopic optics and camera systems.
Light Output Comparable to a 180 W Xenon Source
The POWER LED 180 offers light output comparable to conventional 180 W Xenon light sources. This allows medical facilities to use LED illumination as an alternative to Xenon technology in endoscopic workstations.
The comparison refers to light output, not electrical power consumption. The unit’s specified power consumption is 70 VA.
Over 50,000 Hours of LED Operation
The LED module has a specified operational life of more than 50,000 hours. Unlike Xenon systems, which require lamp replacement during their service life, the POWER LED 180 does not use a conventional Xenon lamp.
This reduces the need to purchase replacement lamps and helps simplify maintenance planning for endoscopy departments.
Integration into Endoscopic Workstations
The POWER LED 180 is intended for use as part of an endoscopic imaging system. Illumination is delivered through an endoscopic light guide, while the camera and monitor provide visualization of the examination or surgical field.
The unit measures 330 × 310 × 90 mm and weighs 5 kg. Its power supply is specified at 115–230 VAC, with an operating input range of 90–263 V and a frequency of 50/60 Hz.
When configuring a workstation, the connection between the light source, light guide and endoscopic optics should be checked for compatibility. The device has a specified BF safety classification.
Technical Specifications
| Specification | POWER LED 180 |
|---|---|
| Reference Number | 103.0180 |
| Dimensions / Weight | 330 × 310 × 90 mm; 5 kg |
| LED Operational Life | >50,000 hours |
| Power Consumption | 70 VA |
| Input Voltage | 115–230 VAC (range 90–263 V) |
| Frequency | 50/60 Hz |
| Colour Temperature | 5,500 K |
| Colour Rendering Index (CRI) | 95 |
| Safety Classification | BF |
